The HFC 227ea Clean Gas Automatic Fire Extinguishing System Protects Museums And Archives
Product Description:
The HFC227ea Clean Agent Fire Suppression System is a cutting-edge, externally pressurized firefighting solution designed to safeguard high-value assets in sensitive environments. Unlike traditional systems, this innovative technology stores fire-extinguishing agent (HFC227ea) and pressurizing nitrogen gas in separate cylinders. Upon activation, nitrogen rapidly pressurizes the agent cylinder, enabling ultra-fast, single-phase delivery of the extinguishing agent through optimized piping networks. This unique design eliminates gas dissolution risks, prevents nitrogen release during discharge, and ensures precise agent distribution without pipe blockages or pressure fluctuations. Compliant with global safety standards (NFPA 2001, ISO 14520), it offers a zero-residue, electrically non-conductive solution ideal for protecting electronics, financial data, and irreplaceable assets.
Key Advantages:
Unmatched Flow Efficiency: Single-phase fluid dynamics allow narrower pipes (up to 40% slimmer than conventional systems) while maintaining higher flow rates, reducing installation costs and space requirements.
Enhanced Reliability: Dual-container storage prevents nitrogen leakage and agent degradation, ensuring consistent performance over decades.
Eco-Safe & Human-Friendly: Zero ozone-depleting potential (ODP=0) with a short atmospheric lifetime (GWP=3,220). Safe for occupied spaces due to rapid dispersion and low toxicity (NOAEL 10.5%).
Technical Parameters:
| Execution Standard |
Q/GZXL001-2021 |
| Model Number |
QMQ5.6/120W-XL |
| Cylinder Capacity |
120L |
| Feature |
Clean Gas And Environmental Friendly |
| Filling Density |
≤1250kg/m³ |
| Operating Temperature Range |
0℃~50℃ |
| Storage Pressure |
0.3MPa ( +20℃) |
| Maximum Operating Pressure |
8MPa (+50℃) |
| System Discharge Time |
≤8 Seconds For Computer Rooms, ≤10 Seconds For Others |
| Fire Extinguishing Design Concentration |
8~10% |
| Fire Suppression Agent |
HFC 227ea |
| Fire Extinguishing Method |
Total Flooding Fire Suppression |
| System Activation Methods |
Automatic, Manual, Mechanical Emergency Start |
| Application Scenario |
Banks and financial institutions |
| System Type |
fm200 system |
Applications:
Financial Institutions: Protect vaults, server rooms, and ATM lobbies from fire damage without harming currency, safety deposit boxes, or blockchain hardware wallets.
Data Centers: Rapidly suppress electrical fires in server racks without triggering corrosion or data loss.
Telecom Hubs: Shield 5G network equipment and backup power systems with non-corrosive, residue-free extinguishing.
Cultural Heritage Sites: Preserve artifacts in museums and archives using gentle yet effective fire containment.
Company profile:
Guangzhou Xinlin Firefighting Equipment Co., Ltd. is located in Guangzhou, a vital city connecting China to the world, characterized by its convenient transportation and picturesque environment. We are a manufacturing company with a professional and seasoned team of employees, consisting of solution design experts, technical installation specialists, quality inspection professionals, and after-sales service teams, dedicated to the research and development of HFC-227ea (FM200), IG541, IG100, and Novec 1230 products.
Currently, we offer a range of commonly used fire suppression systems, including FM200 fire suppression systems, cabinet-style FM200 fire suppression systems, fully automatic FM200 extinguishers (ceiling-mounted), IG541 fire suppression systems, IG100 fire suppression systems, fire detection tube fire suppression systems, as well as automatic fire extinguishing pipelines.
