FM200 Automatic Fire Suppression System 4.2Mpa Fire Extinguisher System For Cabin

1
MOQ
US$500-US$800
Price
FM200 Automatic Fire Suppression System 4.2Mpa Fire Extinguisher System For Cabin
Features Gallery Product Description Request A Quote
Features
Specifications
Model Number: QMQ4.2/120N-XL
Fire Extinguishing Agent Composition: Hfc-227ea
Working Pressure At 20℃: 4.2MPa
Working Pressure Temperature: 0~50℃
Maximum Working Pressure At 50℃: 950kg/M³
Activation Method: Automatic, Pneumatic, Manual, Mechanical Emergency Operation
Fire Extinguishing Mode: Enclosed Flooding
Applications: University Computer Center Server Rooms
Color: Red
Basic Infomation
Place of Origin: China
Brand Name: XL
Certification: UL,FM,CMA,CNAS,CAL
Model Number: QMQ4.2/120N-XL
Payment & Shipping Terms
Packaging Details: Plywood Outer Box With Bubble Bag Or Paper
Delivery Time: 10 Days, Subject To Quantity Negotiation
Payment Terms: L/C,D/P,T/T,Western Union,Paypal,Credit Card
Supply Ability: 100000 Sets Per Week
Product Description

FM200 Automatic Fire Suppression System 4.2Mpa Fire Extinguisher System For Cabin



Technical parameter:

NO. Specifications 4.2Mpa system 5.6Mpa system
1 Capacity 90L,100L,120L,150L,180L 90L,100L,120L,150L,180L
2 Executive Standads GB25972-2010 GB25972-2010
3 Filling pressure 4.2Mpa 5.6Mpa
4 Max filling rate 0.95kg/L 1.08kg/L
5 Discharge time Computer room<8s,others10s
6 Power DC24V/1.6A
7 Fire extinguishing design concentration  8-10%
8 Storage surroundings Temperature:0~50℃
Relative humidity:≤97%
9 Proportion ≤800m²
10 Volume ≤3600m³







Description:



The FM200 fire suppression system plays a significant role as a highly popular and effective solution for fire suppression in enclosed spaces. It selects FM200, a clean gas, as the fire-extinguishing medium. This fire-extinguishing medium is well-known for its ability to rapidly extinguish fires and have a negligible impact on the environment. The FM200 fire suppression system is frequently employed in sensitive areas such as data centers, server rooms, control rooms, museums, laboratories, and other places where water-based fire suppression methods could cause severe damage or disruption.
In terms of response time, the FM200 system is designed for rapid activation. It can detect a fire and release the inert gas within seconds, effectively suppressing the fire in its early stages. Water - based systems may require more time to activate, especially if they rely on manual operation or complex piping systems for water distribution.





Application:



University server rooms stand out as some of the most vital areas where FM200 fire suppression systems find crucial application. These spaces are typically packed with high-density server racks, networking gear, and storage systems that function around the clock to underpin the IT infrastructure across the entire campus. Given the high concentration of electrical components and the presence of ventilation systems, fires in such settings can erupt and spread swiftly, resulting in dire repercussions for academic activities. FM200 fire suppression systems are engineered to identify and douse fires at their nascent stages, thereby curbing damage and guaranteeing uninterrupted service provision.

This system meshes effortlessly with the pre-existing infrastructure, featuring automated fire detection and suppression mechanisms that spring into action mere seconds after a fire is detected. Such a prompt response is pivotal in averting the intensification of fires, which can rapidly engulf server rooms and wreak extensive havoc. The clean agent attributes of FM200 obviate the necessity for post-fire cleanup, enabling universities to swiftly resume their operations with minimal interruptions. This is of paramount importance in academic environments, where even short-lived disruptions can throw research projects, online learning platforms, and administrative systems into disarray.

Beyond server rooms, FM200 fire suppression systems boast broad applicability in other high-value zones within university campuses, encompassing research laboratories, libraries, and administrative data centers. These settings grapple with common issues: the imperative for rapid fire suppression, safeguarding of delicate materials, and a minimal ecological footprint. The adaptability of FM200 renders it apt for a wide array of uses, furnishing a cohesive fire protection strategy that spans the diverse facilities of a university.





Company profile:



Guangzhou Xinlin Firefighting Equipment Co., Ltd. is located in Guangzhou, a vital city connecting China to the world, characterized by its convenient transportation and picturesque environment. We are a manufacturing company with a professional and seasoned team of employees, consisting of solution design experts, technical installation specialists, quality inspection professionals, and after-sales service teams, dedicated to the research and development of HFC-227ea (FM200), IG541, IG100, and Novec 1230(Fk-5-1-12) products.
Currently, we offer a range of commonly used fire suppression systems, including FM200 fire suppression systems, cabinet-style FM200 fire suppression systems, fully automatic FM200 extinguishers (ceiling-mounted), IG541 fire suppression systems, IG100 fire suppression systems, fire detection tube fire suppression systems, as well as automatic fire extinguishing pipelines.



Frequently Asked Questions:

Q1: Are you a manufacturer or a trading company?
A1: We are a professional manufacturer specializing in gas fire suppression systems.

Q2: Can you give me a sample order?


A2: Yes, of course you can. We welcome you to order samples to test and check the product quality. Provide mixed samples.

Q3: Do you offer OEM products?


A3: Yes, we welcome your own designs and drawings.

Q4: Where is your factory located?


A4: Our factory is situated in the East Lake Industrial Park of XinTang Town, Zengcheng District, Guangzhou City, Guangdong Province, China.

Q5: How can I get to your factory?


A5: Due to convenient transportation, you can reach us by taxi or by subway. If taking the subway, please take Line 13 to Shacun Station. Before disembarking, kindly inform us in advance, and we will arrange for a comfortable business van to pick you up from there.
